5G NR Solution-1(RR58041-11)
产品详情
应用与特点
◆ Size: 3x5 mm^2(P2P Compatible with QM75041)
◆ 5G-NR supporting full n41 (2.496-2.690 GHz) Band
● Integrated filtering for full n41(2.496-2.690 GHz) Band
● Integrated SPDT switch and coupler
◆ Full Power APT support without DPD
◆ LTE Power Class 2 High Power User Equipment (HPUE)
◆ 5G N41 Power Class 2 up to 4.5V Vcc
● MPR-0 Prated: 29dBm
◆ Optimized for APT DCDC operation, ET compatible with VCC Capacitor Switch (built in cap)
◆ MIPI v2.1 compliant 52 MHz RFFE bus
◆ Support DFT-S-OFDM/CP-OFDM waveform up to 100 MHz
◆ Support Fast SRS Hopping timing requirements
